BERNSTEIN
Inductive sensor (Type 68 x 30 mm, 40 x 40 mm)
- Sensor Ø16 mm, 6m cable
- Rectangular housing
Selected variant
Specifications
| IP Class | IP67 |
|---|---|
| LED | Yes |
| Load Max | 200 mA |
| Material of body | Plastic |
| Mounting | Non flush |
| Output | PNP NO |
| Sensor type | Inductive |
| Size | 40x40x40 |
|---|---|
| Temperature range from | -25 °C |
| Temperature range to | 70 °C |
| Voltage DC max | 30 V |
| Voltage DC min | 10 V |
Downloads
