Selected variant
Specifications
| 12694_Output function | NO |
|---|---|
| Electrical connection | Cable 2 m |
| IP Class | IP67 |
| LED | Yes |
| Load Max | 200 mA |
| Manufacturer Part No | 6502905022 |
| Material of body | Nickel-plated brass |
| Mounting | Flush mounted |
| Output | PNP |
| Sensing | 8 mm |
|---|---|
| Sensor type | Inductive |
| Size | M18 |
| Temperature range from | -25 °C |
| Temperature range to | 70 °C |
| Voltage DC max | 36 V |
| Voltage DC min | 10 V |
Downloads
