BAILEY & MACKEY
Selected variant
Specifications
| Adjustment range max | 0.25 bar |
|---|---|
| Adjustment range min | 0 bar |
| Connection Thread | G1/4 female |
| IP Class | IP65 |
| Material of seals | NBR |
| Materials Wetted Parts | Brass |
| Max. pressure | 0.275 bar |
| Membrane Material | Beryllium copper |
| Response Time | 10 ms |
|---|---|
| Supply Voltage DC Max | 30 V DC |
| Supply Voltage DC Min | 14 V DC |
| Temperature range from | 0 °C |
| Temperature range to | 50 °C |
| Weight | 1.2 kg |
