YSLY PVC cable fits excellently in various indoors applications as power or control cable. Can be used for example in conveyor belts, packaging machines, machining tools and wood working machinery.
Articles | Nominal Voltage |
---|---|
![]()
SAB02000205/04K
YSLY-OZ 2x0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000305/04K
YSLY-JZ 3G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000405/04K
YSLY-JZ 4G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000505/04K
YSLY-JZ 5G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000705/04K
YSLY-JZ 7G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000805/04
YSLY-JZ 8G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02001005/04K
YSLY-JZ 10G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02001205/04K
YSLY-JZ 12G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02001405/04K
YSLY-JZ 14G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02001805/04K
YSLY-JZ 18G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02002505/04K
YSLY-JZ 25G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02003005/04K
YSLY-JZ 30G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02003405/04
YSLY-JZ 34G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02004205/04K
YSLY-JZ 42G0,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000207/04K
YSLY-OZ 2x0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02000307/04K
YSLY-JZ 3G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02000407/04K
YSLY-JZ 4G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02000507/04K
YSLY-JZ 5G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02000607/04K
YSLY-JZ 6G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02000707/04K
YSLY-JZ 7G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02000807/04K
YSLY-JZ 8G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02000907/04K
YSLY-JZ 9G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02001007/04
YSLY-JZ 10G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02001207/04K
YSLY-JZ 12G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02001507/04K
YSLY-JZ 15G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02001807/04K
YSLY-JZ 18G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02002107/04K
YSLY-JZ 21G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02002507/04K
YSLY-JZ 25G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02003407/04K
YSLY-JZ 34G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02004107/04K
YSLY-JZ 41G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02005007/04K
YSLY-JZ 50G0,75 mm²
|
Uo/U 300/500 V |
![]()
SAB02000210/04K
YSLY-OZ 2x1 mm²
|
Uo/U 300/500 V |
![]()
SAB02000310/04K
YSLY-JZ 3G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02000410/04K
YSLY-JZ 4G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02000510/04K
YSLY-JZ 5G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02000710/04K
YSLY-JZ 7G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02000810/04K
YSLY-JZ 8G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02001210/04K
YSLY-JZ 12G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02001410/04K
YSLY-JZ 14G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02001810/04K
YSLY-JZ 18G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02002110/04K
YSLY-JZ 21G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02002510/04K
YSLY-JZ 25G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02003410/04
YSLY-JZ 34G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02004110/04K
YSLY-JZ 41G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02005010/04
YSLY-JZ 50G1 mm²
|
Uo/U 300/500 V |
![]()
SAB02000215/04K
YSLY-OZ 2x1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000315/04K
YSLY-JZ 3G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000415/04K
YSLY-JZ 4G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000515/04K
YSLY-JZ 5G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000715/04K
YSLY-JZ 7G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000815/04
YSLY-JZ 8G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02001015/04K
YSLY-JZ 10G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02001215/04K
YSLY-JZ 12G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02001415/04K
YSLY-JZ 14G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02001815/04K
YSLY-JZ 18G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02002015/04K
YSLY-JZ 20G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02002515/04K
YSLY-JZ 25G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02003415/04K
YSLY-JZ 34G1,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000225/04K
YSLY-OZ 2x2,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000325/04K
YSLY-JZ 3G2,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000425/04K
YSLY-JZ 4G2,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000525/04K
YSLY-JZ 5G2,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000725/04K
YSLY-JZ 7G2,5 mm²
|
Uo/U 300/500 V |
![]()
SAB02000240/04K
YSLY-OZ 2x4 mm²
|
Uo/U 300/500 V |
![]()
SAB02000440/04K
YSLY-JZ 4G4 mm²
|
Uo/U 300/500 V |
![]()
SAB02000540/04K
YSLY-JZ 5G4 mm²
|
Uo/U 300/500 V |
![]()
SAB02000740/04K
YSLY-JZ 7G4 mm²
|
Uo/U 300/500 V |
![]()
SAB02000360/04K
YSLY-JZ 3G6 mm²
|
Uo/U 300/500 V |
![]()
SAB02000460/04K
YSLY-JZ 4G6 mm²
|
Uo/U 300/500 V |
![]()
SAB02000560/04K
YSLY-JZ 5G6 mm²
|
Uo/U 300/500 V |
![]()
SAB02000760/04K
YSLY-JZ 7G6 mm²
|
Uo/U 300/500 V |
![]()
SAB02000361/04K
YSLY-JZ 3G10 mm²
|
Uo/U 300/500 V |
![]()
SAB02000461/04K
YSLY-JZ 4G10 mm²
|
Uo/U 300/500 V |
![]()
SAB02000561/04K
YSLY-JZ 5G10 mm²
|
Uo/U 300/500 V |
![]()
SAB02000362/04K
YSLY-JZ 3G16 mm²
|
Uo/U 300/500 V |
![]()
SAB02000462/04K
YSLY-JZ 4G16 mm²
|
Uo/U 300/500 V |
![]()
SAB02000562/04K
YSLY-JZ 5G16 mm²
|
Uo/U 300/500 V |
![]()
SAB02000463/04K
YSLY-JZ 4G25 mm²
|
Uo/U 300/500 V |
![]()
SAB02000563/04K
YSLY-JZ 5G25 mm²
|
Uo/U 300/500 V |
![]()
SAB02000464/04K
YSLY-JZ 4G35 mm²
|
Uo/U 300/500 V |
![]()
SAB02000564/04K
YSLY-JZ 5G35 mm²
|
Uo/U 300/500 V |
![]()
SAB02000465/04
YSLY-JZ 4G50 mm²
|
Uo/U 300/500 V |
![]()
SAB02000466/04
YSLY-JZ 4G70 mm²
|
Uo/U 300/500 V |
![]()
SAB02000467/04
YSLY-JZ 4G95 mm²
|
Uo/U 300/500 V |
Number Of leads | 2 |
---|---|
Cross-Section | 0,5 mm² |
Material Outer Jacket | PVC |
Shielded | No |
Nominal Voltage | Uo/U 300/500 V |
Diameter Outer -5% | 5 mm |
Temperature Range The Use Of | 80 °C |
Temperature Range The Use Of | -40 °C |
Temperature Range For Flexible Use | 80 °C |
Temperature Range Flexible Use Of | -40 °C |
Bending Radius Fixed Laying | Min. 7,5 x d |
Bending Radius Flexible Use | Min. 7,5 x d |
Copper Weight | 9,6 kg/km |
Weight | 36 kg/km |
Core Insulation | PVC |
Core identification | Number Coded |
Approvals | RoHS |
Test Voltage | 4000 V |
Area of application | Flexible use |
Colour Outer Sheath | Grey |
