STEGO

Heating element 15-150W - HG 140

HG

The heat source in the element consists of a PTC element – a semi-conductor that adapts its output to the ambient temperature.

The PTC element has a high starting current and provides full output almost immediately. The current then falls quickly and the element is thereafter self-regulating, meaning that the warmer the surroundings, the less output produced by the element.

Thanks to the chimney effect, meaning that the cold air is drawn into the element's bottom and blows out at the top, good self-circulation is achieved for the heated air.

The addition of Pressure Clamp terminals saves time and simplifies the installation.

Dynamic heating (PTC element)
Compact
Energy saving
Quick connector and quick installation

Selected variant

Save as pdf

Technical data / Documents

Product description

Accessories & Related products

Selected variant

Specifications

Approvals	CE, EAC, Gost R, RoHS, UL E150057, VDE
Depth	60 mm
Heat Output	150 W
Heater	Anodized aluminum
Height	259 mm
Humidity Storage	<90% RH
IP Class	IP20
Nominal voltage	120-240 V AC/DC
Operating Humidity	< 90% RH
Operational Temperature	-45°C ... +70°C

Pre fuse (slow)	10 A
Protection Class	I (earthed)
Starting Current Max	9 A
Storage temperature	-45°C ... +70°C
Weight	0,7 kg
Width	70 mm
Voltage max	265 V ac/dc
Voltage min	110 V ac/dc

Downloads

Measurements and connections

Product description

The heat source in the element consists of a PTC element – a semi-conductor that adapts its output to the ambient temperature.

Thanks to the chimney effect, meaning that the cold air is drawn into the element's bottom and blows out at the top, good self-circulation is achieved for the heated air.

The addition of Pressure Clamp terminals saves time and simplifies the installation.

Articles	Approvals	Heat Output	Height	Nominal voltage	Pre fuse (slow)	Starting Current Max	Weight	Voltage max	Voltage min
HG 140 150W Heater, 110-250V ac/dc Art: 14008.0-00 Copied	CE, EAC, Gost R, RoHS, UL E150057, VDE	150 W	259 mm	120-240 V AC/DC	10 A	9 A	0,7 kg	265 V ac/dc	110 V ac/dc
HG 140 15W Heater, 12-36V ac/dc Art: 14010.0-00 Copied	CE, EAC, Gost R, RoHS, VDE	15 W	104 mm	24 V AC/DC		9 A	0,3 kg	36 V ac/dc	12 V ac/dc
HEATER HG140 30W-12-36 VAC/DC Art: 14011.0-00 Copied	CE, EAC, Gost R, RoHS, VDE	30 W	104 mm	24 V AC/DC		14 A	0,3 kg	36 V ac/dc	12 V ac/dc
HG 140 45W Heater, 12-36V ac/dc Art: 14012.0-00 Copied	CE, EAC, Gost R, RoHS, VDE	45 W	104 mm	24 V AC/DC		8 A	0,3 kg	36 V ac/dc	12 V ac/dc
HG 140 60W Heater, 12-36V ac/dc Art: 14013.0-00 Copied	CE, EAC, Gost R, RoHS, VDE	60 W	179 mm	24 V AC/DC		10 A	0,4 kg	36 V ac/dc	12 V ac/dc
HG 140 75W Heater, 12-36V ac/dc Art: 14014.0-00 Copied	CE, EAC, Gost R, RoHS, VDE	75 W	179 mm	24 V AC/DC		12 A	0,5 kg	36 V ac/dc	12 V ac/dc
HG 140 100W Heater, 12-36V ac/dc Art: 14015.0-00 Copied	CE, EAC, Gost R, RoHS, VDE	100 W	179 mm	24 V AC/DC		16 A	0,5 kg	36 V ac/dc	12 V ac/dc
HG 140 150W Heater, 12-36V ac/dc Art: 14016.0-00 Copied	CE, EAC, Gost R, RoHS, VDE	150 W	259 mm	24 V AC/DC		23 A	0,7 kg	36 V ac/dc	12 V ac/dc
HG 140 15W Heater, 110-250V ac/dc Art: 14000.0-00 Copied	CE, EAC, Gost R, RoHS, UL E150057, VDE	15 W	104 mm	120-240 V AC/DC	2 A	1,5 A	0,3 kg	265 V ac/dc	110 V ac/dc
HG 140 30W Heater, 110-250V ac/dc Art: 14001.0-00 Copied	CE, EAC, Gost R, RoHS, UL E150057, VDE	30 W	104 mm	120-240 V AC/DC	4 A	3 A	0,3 kg	265 V ac/dc	110 V ac/dc
HG 140 45W Heater, 110-250V ac/dc Art: 14003.0-00 Copied	CE, EAC, Gost R, RoHS, UL E150057, VDE	45 W	104 mm	120-240 V AC/DC	4 A	3,5 A	0,3 kg	265 V ac/dc	110 V ac/dc
HG 140 60W Heater, 110-250V ac/dc Art: 14005.0-00 Copied	CE, EAC, Gost R, RoHS, UL E150057, VDE	60 W	140 mm	120-240 V AC/DC	4 A	2,5 A	0,4 kg	265 V ac/dc	110 V ac/dc
HG 140 75W Heater, 110-250V ac/dc Art: 14006.0-00 Copied	CE, EAC, Gost R, RoHS, UL E150057, VDE	75 W	179 mm	120-240 V AC/DC	6,3 A	4 A	0,5 kg	265 V ac/dc	110 V ac/dc
HG 140 100W Heater, 110-250V ac/dc Art: 14007.0-00 Copied	CE, EAC, Gost R, RoHS, UL E150057, VDE	100 W	179 mm	120-240 V AC/DC	8 A	4,5 A	0,5 kg	265 V ac/dc	110 V ac/dc
