Honsberg - LABO XF Series Flow Meter
Dynamic diaphragm (flap)
Model XF is a compact flow sensor in PPS plastic or stainless for water applications. Measurement takes place via a spring mounted metal plate which gives a rapid response time, low pressure drop, and high accuracy. The design with no moving parts makes it suitable for applications where this is a requirement. XF can be simply combined with Honsberg's Omni- or Flex technology.
- For liquids up to 16 bar
- Flow from 1 l/min. to 80 l/min.
- Connection from 1/4" to 3/4"
- Housing in PPS or stainless
Selected variant
Specifications
| Flow Max l/min Double | 120 l/min |
|---|---|
| Flow Range Max | 15 l/min |
| Flow Range Min | 1 l/min |
| IP Class | IP67 |
| Load Max | 100 mA |
| Material of body | PPS |
| Material of connection | Nickel-plated brass |
| Material of seals | Viton |
| Material tinplate | Stainless steel 1.4031k |
| Power Consumption | 20 mA |
| Pressure Range Max | 16 bar |
|---|---|
| Temperature range of media from | 0 °C |
| Temperature range of media to | 70 °C |
| Type of flow component | Flow Measuring |
| Weight | 0.35 kg |
| Viscosity Max | 1 cSt |
| Voltage DC max | 30 V |
| Voltage DC min | 10 V |
Product description
Model XF is a compact flow sensor in PPS plastic or stainless for water applications. Measurement takes place via a spring mounted metal plate which gives a rapid response time, low pressure drop, and high accuracy. The design with no moving parts makes it suitable for applications where this is a requirement. XF can be simply combined with Honsberg's Omni- or Flex technology.
