Honsberg - HD2K Series Flow Switch
Piston
Model HD2K is a flow switch for oil and other viscous media. It has a scale that shows where in the working range you have set the switching point. The switch can also deal with highly viscous media, which makes it highly suitable for hydraulic applications.
Special versions
• Ex/ATEX version
• Version for higher pressure PN 500 bar
• Integrated flow meter
• Integrated temperature gauge
- Switching Range 0,5..60 l/min
- Oil
- G¼" up to G1"
- Brass or Stainless Steel Wetted Parts
- Max Pressure 200 bar
Selected variant
Specifications
| Contact Rating Max | 50 VA |
|---|---|
| Flow Max l/min Double | 12 l/min |
| Flow Range Max | 8 l/min |
| Flow Range Min | 0.5 l/min |
| IP Class | IP65 |
| Material Bolt | Brass |
| Material of body | Nickel-plated brass |
| Material of seals | NBR |
| Materials Spring | Stainless steel 301 |
| Pressure Range Max | 200 bar |
|---|---|
| Temperature range of media to | 120 °C |
| Type of flow component | Flow Switches |
| Weight | 1.4 kg |
| Viscosity Max | 330 cSt |
| Viscosity Min | 30 cSt |
| Voltage AC / DC Max | 175 V |
Product description
Model HD2K is a flow switch for oil and other viscous media. It has a scale that shows where in the working range you have set the switching point. The switch can also deal with highly viscous media, which makes it highly suitable for hydraulic applications.
Special versions
• Ex/ATEX version
• Version for higher pressure PN 500 bar
• Integrated flow meter
• Integrated temperature gauge
