SENSECA
Honsberg - MR1K Series Flow Switch
Piston
Model MR1K is a flow switch for liquids and air/gases. It is in a robust and compact version. The switch can be ordered in a large variety of special versions including integrated flow meter, selectable switching range and high pressure version.
Special versions
• Air version
• Integrated flow meter with visual scale
• High pressure version 500 bar
• Double switch heads
- Switching Range 0,4..60 l/min H²O
- Water (oils, gases and aggressive media available on request)
- G¼ up to G1
- Brass or Stainless Steel Wetted Parts
- Max Pressure 200 bar
Selected variant
Specifications
| Contact Rating Max | 50 VA |
|---|---|
| Flow Max l/min Double | 10 l/min |
| Flow Range Max | 4 l/min |
| Flow Range Min | 0.4 l/min |
| IP Class | IP65 |
| Material Bolt | Brass |
| Material of body | Nickel-plated brass |
| Material of seals | NBR |
| Materials Spring | Stainless steel 301 |
| Pressure Range Max | 200 bar |
|---|---|
| Temperature range of media from | -20 °C |
| Temperature range of media to | 120 °C |
| Type of flow component | Flow Switches |
| Weight | 1.3 kg |
| Viscosity Max | 30 cSt |
| Viscosity Min | 1 cSt |
| Voltage AC max | 120 V |
Product description
Model MR1K is a flow switch for liquids and air/gases. It is in a robust and compact version. The switch can be ordered in a large variety of special versions including integrated flow meter, selectable switching range and high pressure version.
Special versions
• Air version
• Integrated flow meter with visual scale
• High pressure version 500 bar
• Double switch heads
