NEOUSYS
Nuvo-8240GC is a rugged edge AI platform designed specifically to support dual NVIDIA® Tesla T4s for advanced inference acceleration applications.
It features NVIDIA multi-precision Turing Tensor Cores and new RT Cores while offering tremendous GPU power up to 130 TFLOPS in FP16 and 520 TOPS in INT4 for emerging GPU-accelerated edge computing and advanced AI inference. In addition, Nuvo-8240GC is powered by Intel® Xeon® E or 9th/ 8th-Gen Core™ CPU up to 8-core/ 16-thread coupled with workstation-grade Intel® C246 chipset to support up to 128 GB ECC or non-ECC DDR4 memory.
The system incorporates one internal 2.5" SATA HDD/ SSD slot and one hot-swappable 2.5" tray for easy HDD/ SSD replacement. There is also an M.2 2280 socket for the ultimate PCIe NVMe SSD. Its front-accessible GbE and USB 3.1 Gen1/ Gen2 ports feature screw-lock mechanisms for secure cable connections. In addition to the dual x16 PCIe slots (8-lanes) for graphics card installation, Nuvo-8240GC has other two x8 PCIe slots (4-lanes)for expansion cards to extend function sets, making it that much more flexible for specific applications such as data collection, analytics and communication.
Nuvo-8240GC has a brand new power delivery design to accept 8~48V wide-range DC input with built-in ignition control. Nuvo-8240GC incorporates Neousys' proven heat dissipation design to allow operating temperatures of -25 - 50°C** (65W processor) and damping brackets for withstanding 3 Grms vibration, making it steady and rocksolid in various conditions. The Nuvo-8240GC is Neousys' response to the never-ending performance demand in industrial edge AI platforms and now with double the inference power, Nuvo-8240GC is ready to take it to the next level.
** By NVIDIA warranty policy operating temperature range of Tesla T4 is 0-50°C
AMT | AMT 12.0 |
---|---|
Chipset | Intel® C246 Platform Controller Hub |
DC Input | 4-pin pluggable terminal block |
Depth | 360 mm |
GPU | Yes |
Graphics | Intel® UHD Graphics 630 |
Hard Drive Interface - Mini-Pcie | 2x full-size mini PCI Express |
Hard Drive Interface - MSATA | 2x full-size mSATA (mux with mini-PCIe) |
Hard Drive Interface - SATA | 1x hot-swap SATA 2.5", 1x internal SATA 2.5", RAID 0/1 support |
Height | 186 mm |
Humidity | 10%~90% , non-condensing |
I / O Ports - Audio | 1x Speaker-out |
I / O Ports - Ethernet Port | 2x Gigabit Ethernet (Intel I219-LM/I210-IT) |
I / O Ports - Serial | 2x software-programmable RS-232/ 422/ 485 ports (COM1/COM2) |
I / O Ports - USB | 4x USB 3.1 Gen2 (10 Gbps), 4x USB 3.1 Gen1 (5 Gbps), 1x USB 2.0 (internal for dongle use) |
I / O Ports - Video | 1x VGA (1920 x 1200), 1x DVI-D (1920 x 1200), 1x DisplayPort (4096 x 2304) |
I/O ports - M.2 | 1x M.2 2280 M key (PCIe Gen3 x4) for NVMe/Optane drive, 1x M.2 2242 B key supporting dual SIM mode with selected M.2 LTE module |
---|---|
I/O ports - PCI Express | 2x PCIe Gen3 x16@x8 for NVIDIA Tesla T4, 2x PCIe Gen3 x8@x4 for add-on card |
Memory RAM | 128 GB |
Mounting | Wall-mount with damping brackets |
Processor | Intel Xeon E 2278GE (8-core/16-thread) |
Supply Voltage DC Max | 48 V DC |
Supply Voltage DC Min | 8 V DC |
Temperature range bearing, from | -40 °C |
Temperature range bearing, to | 85 °C |
Temperature range from | -25 °C |
Temperature range to | 60 °C |
TPM | TPM 2.0 |
Type of memory | 4x ECC/ non-ECC DDR4 2133 SDRAM SODIMM |
Weight | 5 kg |
Width | 170 mm |
Nuvo-8240GC is a rugged edge AI platform designed specifically to support dual NVIDIA® Tesla T4s for advanced inference acceleration applications.
It features NVIDIA multi-precision Turing Tensor Cores and new RT Cores while offering tremendous GPU power up to 130 TFLOPS in FP16 and 520 TOPS in INT4 for emerging GPU-accelerated edge computing and advanced AI inference. In addition, Nuvo-8240GC is powered by Intel® Xeon® E or 9th/ 8th-Gen Core™ CPU up to 8-core/ 16-thread coupled with workstation-grade Intel® C246 chipset to support up to 128 GB ECC or non-ECC DDR4 memory.
The system incorporates one internal 2.5" SATA HDD/ SSD slot and one hot-swappable 2.5" tray for easy HDD/ SSD replacement. There is also an M.2 2280 socket for the ultimate PCIe NVMe SSD. Its front-accessible GbE and USB 3.1 Gen1/ Gen2 ports feature screw-lock mechanisms for secure cable connections. In addition to the dual x16 PCIe slots (8-lanes) for graphics card installation, Nuvo-8240GC has other two x8 PCIe slots (4-lanes)for expansion cards to extend function sets, making it that much more flexible for specific applications such as data collection, analytics and communication.
Nuvo-8240GC has a brand new power delivery design to accept 8~48V wide-range DC input with built-in ignition control. Nuvo-8240GC incorporates Neousys' proven heat dissipation design to allow operating temperatures of -25 - 50°C** (65W processor) and damping brackets for withstanding 3 Grms vibration, making it steady and rocksolid in various conditions. The Nuvo-8240GC is Neousys' response to the never-ending performance demand in industrial edge AI platforms and now with double the inference power, Nuvo-8240GC is ready to take it to the next level.
** By NVIDIA warranty policy operating temperature range of Tesla T4 is 0-50°C
DF Electric is specialized in the manufacturing of fuse links, fuse holders and control transformers since 1987. Presently the company is leading the Spanish market and is also very active in many export markets due to its competitive range of products.
Henkel has launched a new solvent-free circuit board protective lacquer developed to meet the stringent requirements of harsh conditions and increasing safety standards.
The Lütze LOCC-Box is an intelligent electronic overcurrent protection device that provides reliable protection for 12/24 V DC systems in a narrow housing measuring just 8.1 mm. Integrated + and - terminals save space on the DIN rail.
Safety curtains and beams provide effective and reliable personal protection and monitoring in a wide range of industrial environments.
Since 2002, 2J Antennas has become a global supplier of antenna solutions, dedicated to developing innovative technologies for an increasingly networked world. Read more!
You can save space and time during installation with BACO multi-function buttons! Read more.
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Articles | Processor | ||
---|---|---|---|
![]()
Nuvo-8240GC Xeon E2278GE
Art:
N8240GC-E2278GE
Copied
|
Intel Xeon E 2278GE (8-core/16-thread)
|
| |
![]()
Nuvo-8240GC Xeon E2278GEL
Art:
N8240GC-E2278GEL
Copied
|
Intel Xeon E 2278GEL (8-core/16-thread)
|
| |
![]()
Nuvo-8240GC Xeon E2176G
Art:
N8240GC-E2176G
Copied
|
Intel Xeon E 2176G (6-core/16-thread)
|
| |
![]()
Nuvo-8240GC Core i7-8700
Art:
N8240GC-I7
Copied
|
Intel Core i7-8700 (6-core/12-thread)
|
| |
![]()
Nuvo-8240GC Core i5-8500
Art:
N8240GC-I5
Copied
|
Intel Core i5-8500 (6-core/6-thread)
|
| |
![]()
Nuvo-8240GC Core i3-8100
Art:
N8240GC-I3
Copied
|
Intel Core i3-8100 (4-core/4-thread)
|
|
Select a variant in the list
