ADVANCED ILLUMINATION
Advanced Illumination - AL150 BALA lighting
Broad Area Linear Array
Designed for applications that require broad illumination over a wide area, or for applications requiring an even broader field of illumintion, utilise 2 BALA bar lights in parallel.
The AL150 bar light series is expandable in 1" increments up to 82".
Power options include:
- C1 connector - for use with DCS series controllers
- C5 connector - for use with Pulsar 320 strobe controller
- Continuous in-line controller - powered by 24V power supply
- Combination strobe/continuous in-line controller - powered by 24V power supply
- Default-OFF strobe/continuous in-line controller - powered by 24V power supply
- Flying/tinned leads - powered by 24V power supply
Other Wavelength options:
- UV - 395
- Blue - 470
- Green - 520
- Red - 625, 660
- Infrared - 880
- White - WHI
For enquiries or quotes for sizes and power options not listed here please contact us.
- Designed to handle a long, wide field with low angle of view
- Available in 25 mm (1 ") increments up to 80"
Selected variant
Specifications
| Approvals | CE, RoHS |
|---|---|
| Feed | C1, C5, IC, I3, I3S, 24 |
| IP Class | IP50 |
| Life Span | 50000 h |
| Temperature range from | 0 °C |
| Temperature range to | 60 °C |
| Wave-Length | WHI, 395, 470, 520, 625, 660, 880 |
Downloads
Product description
Designed for applications that require broad illumination over a wide area, or for applications requiring an even broader field of illumintion, utilise 2 BALA bar lights in parallel.
The AL150 bar light series is expandable in 1" increments up to 82".
Power options include:
- C1 connector - for use with DCS series controllers
- C5 connector - for use with Pulsar 320 strobe controller
- Continuous in-line controller - powered by 24V power supply
- Combination strobe/continuous in-line controller - powered by 24V power supply
- Default-OFF strobe/continuous in-line controller - powered by 24V power supply
- Flying/tinned leads - powered by 24V power supply
Other Wavelength options:
- UV - 395
- Blue - 470
- Green - 520
- Red - 625, 660
- Infrared - 880
- White - WHI
For enquiries or quotes for sizes and power options not listed here please contact us.
