ADVANCED ILLUMINATION
Advanced Illumination - BL-S100150 EuroBrite™
Strobe/Continuous Backlight
With complete built in control for continuous and strobe modes, the Eurobrite™ range outdoes the comptetition in many ways.
One major feature of the Eurobrite™ is Adaptive Power™ which utilizes an onboard thermistor to maximize light output in continuous mode.
As well as Adaptive Power™ to provide maximal output pulse in strobe mode regardless of the exposure period.
Additional features:
- IP67 sealed enclosure suitable for washdown environments
- Rugged construction that has been tested to withstand over 1000lb
- Industrial grade LEDs providing high-intensity surface illumination of 38klux
For other wavelength options not listed here please contact us.
- Doubel the size of the BL-S050075
- Cost-effective, feature-rich design
- On-board smart driver - seamless strobe or continuous
- IP67 enclosure
Selected variant
Specifications
| Approvals | CE, RoHS |
|---|---|
| Feed | M12 |
| IP Class | IP67 |
| Life Span | 50000 h |
| Temperature range from | 0 °C |
| Temperature range to | 60 °C |
| Wave-Length | WHI, 455, 470, 505, 530, 590, 625, 660, 730, 850, 940 |
Downloads
Product description
With complete built in control for continuous and strobe modes, the Eurobrite™ range outdoes the comptetition in many ways.
One major feature of the Eurobrite™ is Adaptive Power™ which utilizes an onboard thermistor to maximize light output in continuous mode.
As well as Adaptive Power™ to provide maximal output pulse in strobe mode regardless of the exposure period.
Additional features:
- IP67 sealed enclosure suitable for washdown environments
- Rugged construction that has been tested to withstand over 1000lb
- Industrial grade LEDs providing high-intensity surface illumination of 38klux
For other wavelength options not listed here please contact us.
