ADVANCED ILLUMINATION
SL191 Pattern Projecting Spot Light
The SL191 is characterized as a Pattern Projecting Spot Light and is designed for applications requiring structured illumination.
Pattern projection is ideal for locating edges, offsets, and assessing topography.
Requires reticle and lens that are sold separately
• For use with standard C Mount 2/3” lenses (3rd party C-Mount 2/3” format vision lenses are compatible)
• Uses negatively patterned 21mm reticle
Available wavelength options include: 455, 530 & 625nm plus White
- For applications requiring structured illumination
- Ideal for locating edges, offsets, and assessing topography
- Kit of 5 standard reticles available
- Custom reticles available on request
Selected variant
Specifications
| Approvals | CE |
|---|---|
| Feed | C1, C5, IC, IE, I3S |
| IP Class | IP50 |
| Life Span | 50000 h |
| Temperature range from | 0 °C |
| Temperature range to | 60 °C |
| Wave-Length | WHI, 455, 530, 625 |
Downloads
Product description
The SL191 is characterized as a Pattern Projecting Spot Light and is designed for applications requiring structured illumination.
Pattern projection is ideal for locating edges, offsets, and assessing topography.
Requires reticle and lens that are sold separately
• For use with standard C Mount 2/3” lenses (3rd party C-Mount 2/3” format vision lenses are compatible)
• Uses negatively patterned 21mm reticle
Available wavelength options include: 455, 530 & 625nm plus White
