| Aperture Range Max | 2 |
|---|---|
| Distortion | -1.42 |
| Filter | 27 |
| Focal Length | 6 mm |
| Focus | Manual |
| Focus distance min | 100 mm |
| Iris | Manual iris |
| Lens Barrel | C-Mount |
|---|---|
| Pixel size min | 3.3 µm |
| Resolution max | 3 MP |
| Sensor size max | 1/1.8" |
| Type of lens | Standard |
| Weight | 0.062 kg |
|
|
|
|
|
|
||
|---|---|---|---|---|---|---|
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
||
|
|
|
|
|
|
| Articles | Aperture Range Max | Distortion | Focal Length | Focus distance min | Sensor size max | Weight | ||
|---|---|---|---|---|---|---|---|---|
Lens C 6mm F2.0 1/1.8" VST
Art:
VS-0620VM
Copied
|
2
|
-1.42
|
6 mm
|
100 mm
|
1/1.8"
|
0.062 kg
|
| |
|
Lens C 8mm F1.8 1/1.8" VST
Art:
VS-0818VM
Copied
|
1.8
|
-1.19
|
8 mm
|
100 mm
|
1/1.8"
|
0.064 kg
|
| |
|
Lens C 12mm F1.8 1/1.8" VST
Art:
VS-1218VM
Copied
|
1.8
|
-0.19
|
12 mm
|
100 mm
|
1/1.8"
|
0.06 kg
|
| |
|
Lens C 16mm F1.8 1/1.8" VST
Art:
VS-1618VM
Copied
|
1.8
|
-0.14
|
16 mm
|
100 mm
|
1/1.8"
|
0.058 kg
|
| |
|
Lens C 25mm F1.8 1/1.8" VST
Art:
VS-2518VM
Copied
|
1.8
|
-0.15
|
25 mm
|
250 mm
|
1/1.8"
|
0.06 kg
|
| |
|
Lens C 35mm F1.8 2/3" VST
Art:
VS-3518VM
Copied
|
1.8
|
-0.12
|
35 mm
|
250 mm
|
2/3"
|
0.048 kg
|
| |
|
Lens C 50mm F2.6 2/3" VST
Art:
VS-5026VM
Copied
|
2.6
|
0.01
|
50 mm
|
400 mm
|
2/3"
|
0.054 kg
|
|
Select a variant in the list
