Selected variant
Specifications
| Aperture Range Max | 1.8 |
|---|---|
| Aperture Range Min | 22 |
| Distortion | -2.1 |
| Filter | 67 |
| Focal Length | 6 mm |
| Focus | Manual |
| Focus distance min | 100 mm |
| Lens Barrel | C-Mount |
| Pixel size min | 2.5 µm |
|---|---|
| Resolution max | 10 MP |
| Sensor size max | 2/3" |
| Weight | 0.24 kg |
| Viewing Angle (Horizontal) 2/3 " | 74.3 |
| Viewing Angle (Vertical) 2/3 " | 58.4 |
