BASLER

2/3\" lenses

  • Sensor size up to 2/3"
  • C-mount

Selected variant

basler.eps

Save as pdf

Technical data / Documents

Accessories & Related products

Selected variant

Specifications

Aperture Range Max 1.3
Aperture Range Min 16
Distortion 15
Filter 25.5
Focal Length 8.5 mm
Focus distance min 100 mm
Lens Barrel C-mount
Sensor size max 2/3"
Weight 0.054 kg

Downloads

Measurements and connections

Accessories

Related

TER - control stations
Product news

Quality solutions for motion controls

TER - Tecno Elettrica Ravasi, is our Italian supplier specializing in the manufacture of control stations. TER has over 60 years of experience in the manufacture of control stations.

Stego Loop Heater lämmityselementit
Product news

LOOP Heater for optimal heat distribution

Thanks to their loop design, LOOP heating elements offer excellent heating performance and ensure optimal heat distribution. Read more now!

PISA-M
Product news

Compact electronic overcurrent protection PISA-M

PISA-M is a 4-channel electronic fuse for 12 and 24 V DC systems. The smallest 4-channel electronic fuse with a width of only 22.5 mm!

Delcon relays
Product news

An effective solution Delcon CRA5

Delcon's CRA5 plug-in relay revolutionizes the control of difficult-to-handle DC loads. Inductive loads, frequent switching, and high DC voltages are a piece of cake for these relays.

Product news

Safety systems and intelligent detection

Inxpect safety radars detect access or presence of operators in dangerous areas and also have the ability to dynamically set the detection and warning zones.

Knowledge

Fully assembled safety edges

With the help of our technical department, we can offer efficient and comprehensive delivery of safety edges, ready for plug-and-play installation.

Articles Aperture Range Max Aperture Range Min Distortion Filter Focal Length Focus distance min Weight
OPTIC C FIX 08.5MM MP 2/3" EOPTICS
Art:
2000035065 Copied
1.3
16
15
25.5
8.5 mm
100 mm
0.054 kg
Lens Edmund Optics CFFL F1.8 f12 mm 2/3"
Art:
2000035066 Copied
1.8
16
2.5
25.5
12 mm
100 mm
0.054 kg
OPTIC C FIX 16MM MP 2/3" EOPTICS
Art:
2000035067 Copied
1.4
16
1.25
25.5
16 mm
100 mm
0.074 kg
Lens Edmund Optics CFFL F1.4 f25 mm 2/3"
Art:
2000035068 Copied
1.4
17
0.7
25.5
25 mm
100 mm
0.048 kg
Lens Edmund Optics CFFL F1.7 f35 mm 2/3"
Art:
2000035069 Copied
1.65
22
0.3
25.5
35 mm
165 mm
0.075 kg
Lens Edmund Optics CFFL F2.0 f50 mm 2/3"
Art:
2000035070 Copied
2
22
0.2
30.5
50 mm
250 mm
0.106 kg
