TAMRON
5MP, 1/1.2\" lenses
The M112FM series has been developed for the large picture area of 1/1.2-inch sensors such as Sony Pregius IMX174 and IMX249. These new fixed focal lenses have been optimized to meet the requirements of new powerful imaging sensors .They offer a high imaging performance free of vignetting and distortion, and are suitable for sensors up to 3.45 μm pixel pitch.
- Sensor size up to 1/1.2"
- Resolution 5MP
- C-mount
Selected variant
Specifications
| Angle of view (Horizontal) 1 / 1.2 " | 70.3 |
|---|---|
| Aperture Range Max | 2.4 |
| Aperture Range Min | 16 |
| Distortion | -1.47 |
| Filter | 35.5 |
| Focal Length | 8 mm |
| Focus | Manual |
| Focus distance min | 100 mm |
| Image Angle (Vertical) 1 / 1.2 " | 54.9 |
| Iris | Manual iris |
| Lens Barrel | C-Mount |
|---|---|
| Pixel size min | 3.45 µm |
| Resolution max | 5 MP |
| Sensor size max | 1/1.2" |
| Type of lens | Standard |
| Weight | 0.086 kg |
| Viewing Angle (Horizontal) 2/3 " | 59.5 |
| Viewing Angle (Vertical) 2/3 " | 45.8 |
Downloads
Product description
The M112FM series has been developed for the large picture area of 1/1.2-inch sensors such as Sony Pregius IMX174 and IMX249. These new fixed focal lenses have been optimized to meet the requirements of new powerful imaging sensors .They offer a high imaging performance free of vignetting and distortion, and are suitable for sensors up to 3.45 μm pixel pitch.
