Datalogic - SG4-Finger
SG4-Finger is a safety light curtain with a range of up to 6 metres.
This Type 4 light curtain maintains the highest safety level according to the latest safety standards EN ISO 13849-1 and EN 62061.
SG4-Finger curtain has built-in monitored reset, an input for monitoring of external contactors and two solid state safety outputs which are also electronically monitored.
This means that the SG4-Finger can work as a "standalone" unit if required and is not in need of any special control unit.
- Range up to 6 m
- Protection height 150-1800 mm
- Type 4 (PLe SIL 3)
- Compact profile
Selected variant
Specifications
| Supply voltage | 24 V DC |
|---|---|
| Function | Manual/Automatic restart, EDM |
| IP Class | IP65 |
| Reaction time | 11 ms |
| Material of body | Aluminium |
| Temperature range to | 55 °C |
| Temperature range from | 0 °C |
| Approvals | CE, cULus, TÜV |
| Scope | 0,2-6 m |
| Protection height | 150 mm |
| Type | Finger and hand protection |
| PL | e (EN ISO 13849-1) |
|---|---|
| SIL | 3 (EN IEC 62061) |
| Voltage Tolerance | ±20 % |
| T1 (Life Time In Years) | 20 |
| Cable Length Max | 50 m |
| Conforming To | EMC, LVD, MD |
| Contact Current Max | 0.5 A |
| DC | 99 % |
| Mttfd | 444 year |
| Number Of Beams | 16 |
Product description
SG4-Finger is a safety light curtain with a range of up to 6 metres.
This Type 4 light curtain maintains the highest safety level according to the latest safety standards EN ISO 13849-1 and EN 62061.
SG4-Finger curtain has built-in monitored reset, an input for monitoring of external contactors and two solid state safety outputs which are also electronically monitored.
This means that the SG4-Finger can work as a "standalone" unit if required and is not in need of any special control unit.
