Selected variant
Specifications
| IP Class | IP65 |
|---|---|
| Reaction time | 11 ms |
| Material of body | Aluminium |
| Temperature range to | 55 °C |
| Temperature range from | 0 °C |
| Approvals | CE, cULus, TÜV |
| Scope | 0,2-6 m |
| Protection height | 150 mm |
| PL | e (EN ISO 13849-1) |
| SIL | 3 (EN IEC 61508) |
| Voltage Tolerance | ±20 % |
|---|---|
| T1 (Life Time In Years) | 20 |
| Cable Length Max | 50 m |
| Conforming To | EMC, LVD, MD |
| Contact Current Max | 0.5 A |
| DC | 98,80% |
| Mttfd | 444 year |
| Number Of Beams | 16 |
