Selected variant
Specifications
| Approvals | CE, cULus, TÜV |
|---|---|
| Conforming To | EMC, LVD, MD |
| IP Class | IP67 |
| Material of body | ABS plastic, Aluminium |
| Output | PNP |
| Reaction time | 1 ms |
| Scope | 0-8 m |
| Sensing distance | 8 m |
| Supply voltage | 24 V DC |
|---|---|
| Temperature range bearing, from | -25 °C |
| Temperature range bearing, to | 70 °C |
| Temperature range from | -25 °C |
| Temperature range to | 55 °C |
| Type of light | IR LED |
| Voltage Tolerance | ±15 % |
