Arion SmartSafe T12 panel

  • Most popular safety fence system
  • System heights 1410, 2080 mm
  • Easy to install

Product description

SmartSafe is a simple and strong system with wire mesh panels without frames with bent edges for increased strength. A cutting kit is available as standard accessory, making it easy to adjust both width and height when assembling.

There are also standard accessories for the system that make it easy to build with our other systems.

Wire meshes: 100×20 mm, wire diameter 3 & 5 mm








Variants

Articles Panel height Panel width System height Weight
1230 mm 200 mm 1410 mm 1,8 kg
1230 mm 300 mm 1410 mm 2,5 kg
1230 mm 400 mm 1410 mm 3,4 kg
1230 mm 500 mm 1410 mm 4 kg
1230 mm 600 mm 1410 mm 4,7 kg
1230 mm 700 mm 1410 mm 5,4 kg
1230 mm 800 mm 1410 mm 6,2 kg
1230 mm 1000 mm 1410 mm 7,6 kg
1230 mm 1200 mm 1410 mm 9 kg
1230 mm 1500 mm 1410 mm 11 kg
1900 mm 200 mm 2080 mm 2,35 kg
1900 mm 300 mm 2080 mm 3,2 kg
1900 mm 400 mm 2080 mm 4,2 kg
1900 mm 500 mm 2080 mm 5,1 kg
1900 mm 600 mm 2080 mm 6 kg
1900 mm 700 mm 2080 mm 6,8 kg
1900 mm 800 mm 2080 mm 7,8 kg
1900 mm 1000 mm 2080 mm 9,1 kg
1900 mm 1200 mm 2080 mm 11,6 kg
1900 mm 1500 mm 2080 mm 14,2 kg

Variant

12020121
Panel 1230x200 mm, T12

spinner symbol

Specifications

Color Black RAL 9005
Mesh size 20x100 mm
Panel height 1230 mm
Panel width 200 mm
System height 1410 mm
Weight 1,8 kg
Wire strenght 3/5 mm

Measurements and connections
