Selected variant
Specifications
| Cable length | 5 m |
|---|---|
| Number of poles | 3 |
| Material Cable | TPU (WSOR) |
| Connection Thread | M8 |
| Material of connection | Brass |
| Drag Chain Tested | Yes |
| IP Class | IP67 |
| LED indicator | Yes |
| Cable diameter | 7,2 +/-0,25 mm |
| Temperature Range For Use In Chain | 60 °C |
| Temperature Range The Use Of Chain | -5 °C |
| Temperature Range The Use Of | -40 °C |
| Temperature Range For Flexible Use | 80 °C |
|---|---|
| Temperature Range Flexible Use Of | -25 °C |
| Color Cable | Black |
| Number Of Ports | 4 |
| Supply Voltage DC Max | 30 V DC |
| Supply Voltage DC Min | 10 V DC |
| Power / Port Max | 2 A |
| Power / tot max | 6 A |
| Temperature range from | -25 °C |
| Temperature range to | 85 °C |
| Central Material | PBT |
Downloads
