Selected variant
Specifications
| Number of poles | 4 |
|---|---|
| Connection Thread | M12 |
| Contact Embodiment | Straight male |
| Material of connection | Brass |
| Shielded | No |
| Coding | A |
| IP Class | IP67 |
| Materials Contacts | Silver plated copper |
| LED indicator | No |
| Current max | 4 A |
| Voltage DC max | 300 V |
|---|---|
| Voltage AC max | 250 V |
| Temperature range from | -25 °C |
| Temperature range to | 90 °C |
| Cable Diameter Max | 8.1 mm |
| Cable Diameter Min | 4.1 mm |
| Cross-Section Max | 0.75 mm² |
| Manufacturer Part No | 1200710039 |
| Material of body | Plastic |
