MOLEX
Molex - M8 Panel mount receptacles female
- 300 mm lead length
- IP67
Selected variant
Specifications
| Number of poles | 3 |
|---|---|
| Connection Thread | M8 |
| Contact Embodiment | Female |
| Material of connection | Brass |
| Cross-Section | 0.25 mm² |
| IP Class | IP67 |
| Current max | 3 A |
| Wire length | 300 mm |
| Panelmounting | M8 |
|---|---|
| Voltage AC max | 60 V |
| Voltage AC / DC Max | 75 V |
| Temperature range from | -25 °C |
| Temperature range to | 90 °C |
| Manufacturer Part No | 1200310015 |
| Mounting | Front flange |
