STEGO
Fan Heater 250-400 W HGL046
The heat source in this heating fan is a resistor element with an integrated safety cut-out.
Thanks to the fan, good air circulation is obtained, while at the same time high heating output can be achieved. The heating fan is therefore a good choice for installation in, for example, enclosures and outdoor cabinets (base stations, ticket vending machines, etc.) for avoiding condensation or maintaining the temperature above a specified level.
To protect against overheating due to fan failure an automatic internal resetable cut out is included as standard.
- Compact
- High heating output
- Long lifetime
- Maintenance-free
Selected variant
Specifications
| Heat Output | 250 W |
|---|---|
| Nominal voltage | 230 V AC |
| Voltage max | 230 V ac |
| Voltage min | 230 V ac |
| Heater | Anodized aluminum, Plastic |
| Pre fuse (slow) | 2 A |
| Height | 182 mm |
| Weight | 1.1 kg |
| Protection Class | I (earthed) |
| IP Class | IP20 |
| Approvals | CE, cULus, EAC, RoHS, UL, UL E150057, UL 508, VDE |
| Flamklass | UL94-V0 |
| Storage temperature | -45°C ... +70°C |
|---|---|
| Operating Humidity | < 90% RH |
| Air Capacity | 45 m³/h |
| Drag Torque For Cable | 0.8 |
| Frequenze | 50/60 Hz |
| Humidity Storage | <90% RH |
| Life span | 50 000 h @ +25 °C |
| Material of body | Eloxerad aluminium |
| Mounting | Clip on, DIN rail |
| Operational Temperature | -45°C ... +70°C |
Downloads
Product description
The heat source in this heating fan is a resistor element with an integrated safety cut-out.
Thanks to the fan, good air circulation is obtained, while at the same time high heating output can be achieved. The heating fan is therefore a good choice for installation in, for example, enclosures and outdoor cabinets (base stations, ticket vending machines, etc.) for avoiding condensation or maintaining the temperature above a specified level.
To protect against overheating due to fan failure an automatic internal resetable cut out is included as standard.
