Selected variant
Specifications
| Approvals | CSA, UL, VDE |
|---|---|
| Cable Diameter Max | 6 mm |
| Cable Diameter Min | 3 mm |
| Hexagon | 14 mm |
| IP Class | IP69K (5 bar, 30 min) |
| Length Overall | 25 mm |
| Material screw | Nickel-plated brass |
| O-ring | Yes |
| Pack Size | 100 |
| Packing Materials | CR/NBR |
|---|---|
| Temperature range dynamic max. | 100 °C |
| Temperature range dynamic min. | -20 °C |
| Temperature range static short term min. | -40 °C |
| Thread Length | 5 mm |
| Thread size | M12x1,5 |
| Thread type | Metric |
