Approvals | CSA, UL |
---|---|
Cable Diameter Max | 6.5 mm |
Cable Diameter Min | 3 mm |
Color | Grey RAL 7001 |
Hexagon | 15 mm |
IP Class | IP68 |
Length Overall | 63.5 mm |
Material screw | Polyamide |
O-ring | No |
Pack Size | 100 |
---|---|
Packing Materials | CR/NBR |
Temperature range dynamic max. | 100 °C |
Temperature range dynamic min. | -20 °C |
Temperature range static short term min. | -40 °C |
Thread Length | 8 mm |
Thread size | M12x1,5 |
Thread type | Metric |
The new WADI product family by Jacob features a completely redesigned gland rubber, which allows extensive sealing and tightening area.
DF Electric is specialized in the manufacturing of fuse links, fuse holders and control transformers since 1987. Presently the company is leading the Spanish market and is also very active in many export markets due to its competitive range of products.
The Lütze LOCC-Box is an intelligent electronic overcurrent protection device that provides reliable protection for 12/24 V DC systems in a narrow housing measuring just 8.1 mm. Integrated + and - terminals save space on the DIN rail.
ComatReleco has launched a new series of push-in sockets specifically designed for time and space savings.
The need for flexible, modular systems shapes machine and system engineering. Decentralization of the system components has proven to be an important factor for success.
Crouzet has honoured the strong Syrelec time relay traditions established in the 1980s, first by Cronos and Cronos 2 series. Now, Crouzet presents the compact and extremely versatile Syr-Line series.
|
|
|
|
|
||
---|---|---|---|---|---|---|
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
||
|
|
|
|
|
Articles | Cable Diameter Max | Cable Diameter Min | Color | Hexagon | Length Overall | Pack Size | Thread Length | Thread size | ||
---|---|---|---|---|---|---|---|---|---|---|
![]()
FÖRSK.M12 MED SKYDDSPIRAL GRÅ
Art:
50007M12PABS
Copied
|
6.5 mm
|
3 mm
|
Grey RAL 7001
|
15 mm
|
63.5 mm
|
100
|
8 mm
|
M12x1,5
|
| |
![]()
Cable gland, M12, plastic, spiral top, grey RAL7035
Art:
50007M12BS7035
Copied
|
6.5 mm
|
3 mm
|
Grey RAL 7035
|
15 mm
|
63.5 mm
|
100
|
8 mm
|
M12x1,5
|
| |
![]()
Cable gland, M12, plastic, spiral top, black RAL9005
Art:
50007M12BSSW
Copied
|
6.5 mm
|
3 mm
|
Black RAL 9005
|
15 mm
|
63.5 mm
|
100
|
8 mm
|
M12x1,5
|
| |
![]()
CABLE GLAND WITH SPIRAL TOP M16
Art:
50011M16PABS
Copied
|
10 mm
|
5 mm
|
Grey RAL 7001
|
22 mm
|
94.5 mm
|
100
|
15 mm
|
M16x1,5
|
| |
![]()
Cable gland, M16, plastic, spiral top, grey RAL7035
Art:
50011M16BS7035
Copied
|
10 mm
|
5 mm
|
Grey RAL 7035
|
22 mm
|
94.5 mm
|
100
|
15 mm
|
M16x1,5
|
| |
![]()
CABLE GLAND WITH SPIRAL TOP M16 BLACK
Art:
50011M16BSSW
Copied
|
10 mm
|
5 mm
|
Black RAL 9005
|
22 mm
|
94.5 mm
|
100
|
15 mm
|
M16x1,5
|
| |
![]()
CABLE GLAND WITH SPIRAL TOP M20
Art:
50013M20PABS
Copied
|
12 mm
|
6 mm
|
Grey RAL 7001
|
24 mm
|
101.5 mm
|
50
|
11 mm
|
M20x1,5
|
| |
![]()
Cable gland, M20, plastic, spiral top, grey RAL7035
Art:
50013M20BS7035
Copied
|
12 mm
|
6 mm
|
Grey RAL 7035
|
24 mm
|
101.5 mm
|
50
|
11 mm
|
M20x1,5
|
| |
![]()
Cable gland, M20, plastic, spiral top, black RAL9005
Art:
50013M20BSSW
Copied
|
12 mm
|
6 mm
|
Black RAL 9005
|
24 mm
|
101.5 mm
|
50
|
11 mm
|
M20x1,5
|
| |
![]()
CABLE GLAND WITH SPIRAL TOP M20
Art:
50016M20PABS
Copied
|
14 mm
|
10 mm
|
Grey RAL 7001
|
27 mm
|
116 mm
|
25
|
15 mm
|
M20x1,5
|
| |
![]()
Cable gland, M20, plastic, spiral top, grey RAL7035
Art:
50016M20BS7035
Copied
|
14 mm
|
10 mm
|
Grey RAL 7035
|
27 mm
|
116 mm
|
25
|
15 mm
|
M20x1,5
|
| |
![]()
Cable gland, M20, plastic, spiral top, black RAL9005
Art:
50016M20BSSW
Copied
|
14 mm
|
10 mm
|
Black RAL 9005
|
27 mm
|
116 mm
|
25
|
15 mm
|
M20x1,5
|
| |
![]()
CABLE GLAND WITH SPIRAL TOP M20
Art:
50021M25PABS
Copied
|
18 mm
|
13 mm
|
Grey RAL 7001
|
33 mm
|
132.5 mm
|
25
|
15 mm
|
M25x1,5
|
| |
![]()
Cable gland, M25, plastic, spiral top, grey RAL7035
Art:
50021M25BS7035
Copied
|
18 mm
|
13 mm
|
Grey RAL 7035
|
33 mm
|
132.5 mm
|
25
|
15 mm
|
M25x1,5
|
| |
![]()
CABLE GLAND WITH SPIRAL TOP M25 BLACK
Art:
50021M25BSSW
Copied
|
18 mm
|
13 mm
|
Black RAL 9005
|
33 mm
|
132.5 mm
|
25
|
15 mm
|
M25x1,5
|
|
Select a variant in the list
