CAL CONTROLS
CAL 9400
CAL 9400 is an efficient yet compact temperature controller. Features thermocouple, Pt100 (2 wire) and mV input. Easy-to-use autotuning, simple configuration. IP66 rated composition.
- Self-tuning of all PID parameters
- Set point value adjustable
- 2 outputs
- Easy to use
Selected variant
Specifications
| Approvals | CE, CSA, EMC, UL, FM |
|---|---|
| Digit Height | 10 mm |
| Digital signal in | No |
| Frequenze | 50-60 |
| IP Class Front | IP66 |
| Material Protection | Polycarbonate |
| Mounting | Panel mount |
| Number Of Digits | 4 |
| Output | Logic (SSR), 1x relay |
|---|---|
| Panel size | 48x48 mm |
| Power Supply AC max | 264 V |
| Power Supply AC min | 90 V |
| Temperature resistance housing to | 50 °C |
| Weight | 130 g |
Product description
CAL 9400 is an efficient yet compact temperature controller. Features thermocouple, Pt100 (2 wire) and mV input. Easy-to-use autotuning, simple configuration. IP66 rated composition.
