CROUZET CONTROL
Current Monitor Relays EIL, EIH and EIT
Selected variant
Specifications
| Approvals | CE, CSA, RoHS, UL |
|---|---|
| Breaking capacity | 8A, 250V AC |
| IP Class Connection | IP20 |
| IP Class Housing | IP50 |
| Measuring range E1-M | 0,1-1A |
| Measuring range E2-M | 0,5-5A |
| Measuring range E3-M | 1-10A |
| Operating Voltage AC Max | 264 V AC |
| Operating Voltage AC Min | 196 V AC |
| Temperature range bearing, from | -30 °C |
| Temperature range bearing, to | 70 °C |
|---|---|
| Temperature range from | -20 °C |
| Temperature range to | 50 °C |
| Threshold Adjustable from | 10 % |
| Threshold Adjustable to | 100 % |
| Time Delay On Crossing The Threshold | 0,1-3s |
| Time Delay Start | 1-20s |
| Weight | 140 g |
