Selected variant
Specifications
| Switching Capability Voltage | 250 V |
|---|---|
| Breaking Capacity Current | 10 A |
| Isolation conn./conn. | 2500 V |
| Isolation connection/rail | 2500 V |
| Material | Lexan |
| Torque Connection | 0.7 |
| Screw size | M3, Pozi |
| Cross section stranded | 0,35-2,5 mm² |
|---|---|
| Temperature range from | -40 °C |
| Temperature range bearing, from | -40 °C |
| Temperature range bearing, to | 80 °C |
| Temperature range to | 60 °C |
| Weight | 55 g |
