AUER SIGNAL
Auer Ex Classified Signal Horn mHPT
Strong well-designed horn for use in areas exposed to explosions in zones 1 and 2.
The housing is made of impact resistant synthetic material.
Insulation class ll.
DC models with electronic switch.
- Strong, well-designed signal horn
- For use in Zone 1 and 2
- Insulation class ll
- IP54, -20 to +70 ° C
Selected variant
Specifications
| Color House | Black |
|---|---|
| IP Class | IP54 |
| Nominal current max | 0.15 A |
| Nominal current min | 0.15 A |
| Number of tones | 1 |
| Operating Voltage AC Max | 122.5 V AC |
| Operating Voltage AC Min | 103.5 V AC |
| Sound level max | 108 dB |
|---|---|
| Sound level min | 108 dB |
| Temperature range from | -20 °C |
| Temperature range to | 60 °C |
| Terminal connection | 2.5 mm² |
| Weight | 500 g |
Downloads
Product description
Strong well-designed horn for use in areas exposed to explosions in zones 1 and 2.
The housing is made of impact resistant synthetic material.
Insulation class ll.
DC models with electronic switch.
