Selected variant
Specifications
| Approvals | CE, EMC |
|---|---|
| Digit Height | 10 mm |
| Digital signal in | No |
| IP Class | IP20 |
| Mounting | DIN rail |
| Number of digits | 2 |
| Numeric Color | Red |
| Output | Relay |
| Power Supply AC max | 264 V |
| Power Supply AC min | 180 V |
|---|---|
| Temperature range bearing, from | -30 °C |
| Temperature range bearing, to | 70 °C |
| Temperature resistance housing from | -20 °C |
| Temperature resistance housing to | 65 °C |
| Weight | 100 g |
| Width | 17.5 mm |
