CONTA-CLIP

Pressure spring double/triple deck terminals FRKD

FRKD,FSLD,

  • Wiring without tools
  • Internally linked versions
  • Colour coded options
  • 2 and 3 connections
  • Electronic component versions

Selected variant


Save as pdf

Technical data / Documents

Accessories & Related products

Selected variant

Specifications

Cross-Section 2.5 mm²
Color Green
Rated Voltage IEC 500 V
Rated Current IEC 24 A
Mounting TS 35/7,5
Rated impulse voltage 6 kV
Overvoltage category III
Contamination degree 3
Approvals CSA, CSA US, KEMA KUR, EAC
Length 75.4 mm
Width 5.1 mm
Height TS 35/7.5 53 mm
Connections 2 x 2
Number of levels 2
Plug gauge acc. EN 60 947-1 A3
Cross connect channels 2
Cross section single wire from 0.2 mm²
Cross section single wire to 4 mm²
Cross section stranded wire from 0.2 mm²
Cross section stranded wire to 4 mm²
Cross section stranded with ferrule from 0.2 mm²
Cross section stranded with ferrule to 2.5 mm²
Rated wire cross section from (AWG) 26
Rated wire cross section to (AWG) 14
Stripping Length 12 mm
Insulation Material Polyamide 6.6
Flamklass UL94-V0
Operating temperature from -40 °C
Operating temperature to 120 °C
Voltage CSA 300 V
Rated Current CSA 20 A
CSA test standard C22.2 No 158
Rated voltage CSAus 300 V
Rated current CSAus 20 A
CSAus test standard UL 1059
EAC test standard TR ZU 004/2011
KEMA KEUR test standard EN 60947-7-1:2009
Tariff code 85369010
Country of origin BG
Weight 14.57 g
Pack Size 100
