SENSECA
Honsberg - TZ1 Series Flow Meter
Piston
Model TZ1 is a mechanical piston-type flow meter. Thanks to its robust design it is highly suitable in heavy industrial or more demanding applications.
Special versions
• 3" to 600 l/min.
• Special scales for oil or gas
• Switch function (NC or NO)
- For liquids up to 100 bar
- Flow from 2 l/min. to 250 l/min. liquid 1-100 cSt
- With or without needle valve
Selected variant
Specifications
| Contact Rating Max | 5 A |
|---|---|
| Flow Max l/min Double | 20 l/min |
| Flow Range Max | 20 l/min |
| Flow Range Min | 4 l/min |
| IP Class | IP65 |
| Material Bolt | Brass |
| Material of body | Bronze |
| Material of seals | NBR |
|---|---|
| Materials Spring | Stainless steel 301 |
| Pressure Range Max | 100 bar |
| Temperature range of media to | 90 °C |
| Type of flow component | Flowmeter |
| Weight | 1.6 kg |
Product description
Model TZ1 is a mechanical piston-type flow meter. Thanks to its robust design it is highly suitable in heavy industrial or more demanding applications.
Special versions
• 3" to 600 l/min.
• Special scales for oil or gas
• Switch function (NC or NO)
