SENSECA
Honsberg - RVM Series Flow Switch
Piston
Mechanical flow switch, for fluid media, with magnetic triggering of a reed switch. Robust construction in brass or stainless steel.
- Swittching Range 0,04..3 l/m H₂O
- Water (gas and aggressive media available on request)
- G¼"
- Brass or Stainless Steel Wetted Parts
- Max Pressure 300 bar
Selected variant
Specifications
| Contact Rating Max | 20 VA |
|---|---|
| Flow Max l/min Double | 0.17 l/min |
| Flow Range Max | 0.13 l/min |
| Flow Range Min | 0.04 l/min |
| IP Class | IP65 |
| Material Bolt | Brass |
| Material of body | Nickel-plated brass |
| Material of seals | NBR |
| Materials Spring | Stainless steel 316Ti |
|---|---|
| Pressure Range Max | 300 bar |
| Temperature range of media to | 100 °C |
| Type of flow component | Flow Switches |
| Weight | 0.14 kg |
| Viscosity | 1 cSt |
| Voltage AC max | 200 V |
Product description
Mechanical flow switch, for fluid media, with magnetic triggering of a reed switch. Robust construction in brass or stainless steel.
