KTC linear motion position sensor, pulling rod type
KTC linear motion position transducers are designed for direct absolute measurement and are available in stroke lengths up to 1250mm. Features:
- Durable bearing and slider
- Anonized aluminium housing
- Smooth low noice output from conductive plastic tack
- Long service life: >100x10⁶ cycles or >25x10⁶ meters
- Maximum operating speed 10m/s
- Robust design for industrial use, long service life
- Stroke length 50-1250 mm
- IP60 or IP65
- Temperature range -30...+100 °C
Selected variant
Specifications
| Working Speed Max | 10 m/s |
|---|---|
| IP Class | IP65, IP60 |
| Stroke min | 50 mm |
| Stroke max | 1250 mm |
| Supply Voltage Max | 60 V |
| Power Consumption min | 3 W |
| Power Consumption max | 10 W |
| Conductor | ≤1 mA |
| Power Resistor | ≤10 mA |
| Linearity | ±0,07 % (50-375 mm), ±0,05 % (400-3 000 mm) |
| Repeatability | ±0,01 mm |
|---|---|
| Operating Force | ≤2 N (KTC), ≤10 N (KTC-P) |
| Resolution | ∞ |
| Vibration Resistance | IEC 68-2-6:1982 10 G |
| Shock Resistance | IEC 68-21968 40 G |
| Temperature range from | -30 °C |
| Temperature range to | 100 °C |
| Temperature range bearing, from | -50 °C |
| Temperature range bearing, to | 120 °C |
Product description
KTC linear motion position transducers are designed for direct absolute measurement and are available in stroke lengths up to 1250mm. Features:
- Durable bearing and slider
- Anonized aluminium housing
- Smooth low noice output from conductive plastic tack
- Long service life: >100x10⁶ cycles or >25x10⁶ meters
- Maximum operating speed 10m/s
