TAKEX
Takex - J Series industriual photoelectric sensor
- Large connection space, substantial screws
- This photoelectric sensor can be plugged into the base
- Programmable time function 0.1-10 s
- IP66
Selected variant
Specifications
| Approvals | CE |
|---|---|
| Distance Max | 10000 mm |
| Distance Min | 0 mm |
| Electrical connection | Cable 2 m |
| Function | Dark On/Light On |
| IP Class | IP66 |
| Lens material | Polyacrylic |
| Light / Dark Switching | Yes |
| Light type | Red LED |
| Output | NPN, PNP |
|---|---|
| Output current max | 0.1 A |
| Photocell technology | Transmitter / receiver |
| Reaction time | 0.5 ms |
| Temperature range from | -25 °C |
| Temperature range to | 55 °C |
| Voltage DC max | 24 V |
| Voltage DC min | 12 V |
