TAKEX
Takex - UM Ultra miniature photosensor with built-in amplifier
The UM series has been produced for users who have stringent requirements for a compact sensor and require a built-in amplifier.
- One-piece, able to withstand vibration
- Short reaction time, 0.5 ms
- Double LED indication
Selected variant
Specifications
| Approvals | CE |
|---|---|
| Distance Min | 0 mm |
| Electrical connection | Cable 2 m |
| Function | Dark On |
| IP Class | IP64 |
| Lens material | Acrylic |
| Light / Dark Switching | No |
| Light type | Red LED |
| Material of body | ABS plastic |
| Output | PNP |
| Output current max | 0.08 A |
|---|---|
| Photocell technology | Transmitter / receiver |
| Power consumption max | 0.03 A |
| Reaction time | 0.5 ms |
| Sensing | 500 mm |
| Temperature range from | -25 °C |
| Temperature range to | 55 °C |
| Voltage DC max | 24 V |
| Voltage DC min | 24 V |
Product description
The UM series has been produced for users who have stringent requirements for a compact sensor and require a built-in amplifier.
