BEI SENSORS
NHM9 tacho encoder for demanding environments
- Diameter 90mm, shaft 11m or 12mm
- Analogue and incremental signal in accordance with rotational speed
- Equipped with cable, connector or connection box
- Mechanical overspeed switch available
Selected variant
Specifications
| IP Class | IP66, IP67 |
|---|---|
| Shaft Diameter | 11 mm |
| Connection Thread | Cable, M23 contact |
| Temperature range to | 80 °C |
| Housing diametre | 90 mm |
| Pulse Max | 10000 |
| Temperature range from | -20 °C |
| Supply Voltage DC Max | 30 V DC |
|---|---|
| Output | 0-10V, 4-20 mA |
| Supply Voltage DC Min | 15 V DC |
| Speed max. | 6000 rpm |
| Sensor type | Absolute |
