MERSEN

Cylindrical fuse link, 14x51, aR

Protistor 14x51 aR are extremely high interrupting rating fuses with large band of ratings . Applications include small inverters, UPS systems, variable speed drives and other similar equipment 700V or less.

Characteristics:

  • Extremely fast acting aR (IEC 60269-4)
  • Current limiting
Read more
  • Fast acting aR
  • 6-63 A
  • Breaking capacity 160 kA
  • 690 VAC (IEC) / 700 VAC (UL) / 500 V DC (UL)
  • With or without striker

Selected variant

mersen.eps

Save as pdf

Technical data / Documents

Product description

Accessories & Related products

Selected variant

Specifications

Approvals CE, CSA, UL
Breaking Capacity 160 kA
Characteristic (CVL) aR
Manufacturer Part No H1027325
Nominal current 6 A
Pack Size 10
Voltage AC max 690 V
Voltage DC max 500 V

Downloads

Measurements and connections

Product description

Protistor 14x51 aR are extremely high interrupting rating fuses with large band of ratings . Applications include small inverters, UPS systems, variable speed drives and other similar equipment 700V or less.

Characteristics:

  • Extremely fast acting aR (IEC 60269-4)
  • Current limiting

Accessories

Related products

Articles Indication (CVL) Manufacturer Part No Nominal current
Protistor semiconductor 14x51 aR 690 VAC 6 A
Art:
FR14AR69V6 Copied
H1027325
6 A
Protistor semiconductor 14x51 aR 690 VAC 8 A
Art:
FR14AR69V8 Copied
J1027326
8 A
Protistor semiconductor 14x51 aR 690 VAC 10 A
Art:
FR14AR69V10 Copied
K1027327
10 A
Protistor semiconductor 14x51 aR 690 VAC 12 A
Art:
FR14AR69V12 Copied
L1027328
12 A
Protistor semiconductor 14x51 aR 690 VAC 16 A
Art:
FR14AR69V16 Copied
M1027329
16 A
Protistor semiconductor 14x51 aR 690 VAC 20 A
Art:
FR14AR69V20 Copied
N1027330
20 A
Protistor semiconductor 14x51 aR 690 VAC 25 A
Art:
FR14AR69V25 Copied
P1027331
25 A
Protistor semiconductor 14x51 aR 690 VAC 32 A
Art:
FR14AR69V32 Copied
Q1027332
32 A
Protistor semiconductor 14x51 aR 690 VAC 40 A
Art:
FR14AR69V40 Copied
R1027333
40 A
Protistor semiconductor 14x51 aR 690 VAC 50 A
Art:
FR14AR69V50 Copied
S1027334
50 A
Protistor semiconductor 14x51 aR 690 VAC 63 A
Art:
FR14AR69V63 Copied
T1027335
63 A
Protistor semiconductor 14x51 aR 690 VAC 6 A with striker
Art:
FR14AR69V6T Copied
Striker
P1056656
6 A
Protistor semiconductor 14x51 aR 690 VAC 8 A with striker
Art:
FR14AR69V8T Copied
Striker
Q1056657
8 A
Protistor semiconductor 14x51 aR 690 VAC 10 A with striker
Art:
FR14AR69V10T Copied
Striker
R1056658
10 A
Protistor semiconductor 14x51 aR 690 VAC 12 A with striker
Art:
FR14AR69V12T Copied
Striker
S1056659
12 A
Protistor semiconductor 14x51 aR 690 VAC 16 A with striker
Art:
FR14AR69V16T Copied
Striker
T1056660
16 A
Protistor semiconductor 14x51 aR 690 VAC 20 A with striker
Art:
FR14AR69V20T Copied
Striker
V1056661
20 A
Protistor semiconductor 14x51 aR 690 VAC 25 A with striker
Art:
FR14AR69V25T Copied
Striker
W1056662
25 A
Protistor semiconductor 14x51 aR 690 VAC 32 A with striker
Art:
FR14AR69V32T Copied
Striker
X1056663
32 A
Protistor semiconductor 14x51 aR 690 VAC 40 A with striker
Art:
FR14AR69V40T Copied
Striker
Y1056664
40 A
Protistor semiconductor 14x51 aR 690 VAC 50 A with striker
Art:
FR14AR69V50T Copied
Striker
Z1056665
50 A
Protistor semiconductor 14x51 aR 690 VAC 63 A with striker
Art:
FR14AR69V63T Copied
Striker
A1056666
63 A

Selected variant

Select a variant in the list
