SENSECA
Honsberg - FW1 Series Flow Switch
Piston
Mechanical flow switch, for fluid media, with spring-supported piston and magnetic triggering of a reed switch. Robust construction in brass and POM
- Switching Range 1..11 l/min H²O
- Water (Oil available on request)
- G¼" up tp G1"
- Brass or POM Wetted Parts
- Max Pressure 10 bar
Selected variant
Specifications
| Contact Rating Max | 0.5 A |
|---|---|
| Flow Max l/min Double | 20 l/min |
| Flow Range Max | 6 l/min |
| Flow Range Min | 1 l/min |
| IP Class | IP67 |
| Material of body | POM |
| Materials Spring | Stainless steel 301 |
| Pressure Range Max | 10 bar |
|---|---|
| Temperature range of media to | 90 °C |
| Type of flow component | Flow Switches |
| Weight | 0.05 kg |
| Voltage AC max | 230 V |
Downloads
Product description
Mechanical flow switch, for fluid media, with spring-supported piston and magnetic triggering of a reed switch. Robust construction in brass and POM
