Takex - GN/DN miniature photoelectric sensor
The GN/DN series is a series of miniature photoelectric sensors with long distances. Modern technology has allowed for the successful manufacture of a range of low-price photoelectric sensors offering high technical performance. The compact housings, together with long distances, make this series appropriate for most applications.
- Miniature version with long distances
- Red visible light
- Cable or connector
- IP67
Selected variant
Specifications
| Approvals | CE |
|---|---|
| Distance Min | 0 mm |
| Electrical connection | Cable 2 m |
| Function | Dark On/Light On |
| IP Class | IP67 |
| Light / Dark Switching | Yes |
| Light type | Red LED |
| Output | PNP |
| Photocell technology | Transmitter / receiver |
| Power consumption max | 0.022 A |
|---|---|
| Reaction time | 0.5 ms |
| Sensing | 10000 mm |
| Temperature range from | -25 °C |
| Temperature range to | 55 °C |
| Voltage DC max | 24 V |
| Voltage DC min | 12 V |
Product description
The GN/DN series is a series of miniature photoelectric sensors with long distances. Modern technology has allowed for the successful manufacture of a range of low-price photoelectric sensors offering high technical performance. The compact housings, together with long distances, make this series appropriate for most applications.
