TAKEX
Takex - NE compact multivoltage photosensor relay output
Compact photoelectric sensor with very long detection distances. Available with both static output and relay output. The photoelectric sensors with relay output also have multivoltage.
- Compact with long distances
- Multivoltage 24-240 V ac/dc
- Alternating relay output
Selected variant
Specifications
| Approvals | CE |
|---|---|
| Distance Min | 0 mm |
| Electrical connection | Cable 2 m |
| Function | Dark On |
| IP Class | IP66 |
| Lens material | Acrylic |
| Light / Dark Switching | Yes |
| Light type | IR LED |
| Material of body | ABS plastic |
| Output | Relay |
|---|---|
| Photocell technology | Transmitter / receiver |
| Reaction time | 5 ms |
| Sensing | 30000 mm |
| Temperature range from | -25 °C |
| Temperature range to | 55 °C |
| Voltage AC / DC Max | 240 V |
| Voltage AC / DC Min | 24 V |
Product description
Compact photoelectric sensor with very long detection distances. Available with both static output and relay output. The photoelectric sensors with relay output also have multivoltage.
